| Wavelength: | 1310nm & 1550nm | Bandwidth(nm): | ± 40 |
|---|---|---|---|
| Operating Temperature: | -20 --- +70 | Lead Length: | 1 M Or More |
| Lead Time: | 5-8 Working Days | Configuration: | 1x4 |
| High Light: | optical fibre splitter,fiber optical splitter |
||
SM DW FBT 1×4 Fiber Optic Splitter 1310nm 1550nm ABS box ± 40 nm Bandwidth
Applications:
Ordering Information
1. Configuration12=1x2, 22=2x2, 18=1x8, 1616=16x16, 132=1x32, etc.
2. Wavelength3=1310nm & 1550nm
3. Coupling Ratio50/50, 40/60, 20/80, 25x4(for 25/25/25/25), etc.
4. Lead Type1=250um, 2=900um, 3=2.0mm, 4=3.0mm
5. Package TypeA1, A3, B, C, D or E
6. Lead Length0.5=0.5m, 1=1m, etc.
7. Connectors Terminated Blank=no connector, FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC
Features:
Specification
|
Characteristics |
Unit |
Value / Performance |
|||||||||||
|
1 * N , 2 * N |
|||||||||||||
|
Configuration |
- |
N*4 N=1,2,4 |
N*8 N=1,2,8 |
N*16 N=1,2,16 |
N*32 N=1,2,32 |
||||||||
|
Center Wavelength |
nm |
1310 and 1550 |
|||||||||||
|
Bandwidth |
nm |
±40 |
|||||||||||
|
Max Excess Loss |
dB |
0.2 |
0.3 |
0.4 |
0.5 |
||||||||
|
Max. Insertion Loss |
dB |
7.0 |
10.5 |
14 |
17.5 |
||||||||
|
Typ. Insertion Loss |
dB |
6.2 |
9.3 |
12.4 |
15.5 |
||||||||
|
Polarization Dependent Loss |
dB |
≤0.2 |
≤0.3 |
≤0.4 |
≤0.5 |
||||||||
|
Thermal Stability |
dB |
≤0.2 |
≤0.3 |
≤0.4 |
≤0.5 |
||||||||
|
Directivity |
dB |
≥60 |
|||||||||||
|
Operating Temperature |
℃ |
-20~+70 |
|||||||||||
|
Lead Length |
m |
One, others on request |
|||||||||||
|
Lead Type |
- |
900um, 2mm or 3mm loose tube |
|||||||||||
|
Package Type |
- |
C |
D |
E |
F |
||||||||
|
Uniformity |
dB |
≤1.6 |
≤2.4 |
≤3.2 |
≤4.0 |
||||||||
|
Characteristics |
Unit |
Value / Performance |
|||||||
|
1 * 2 , 2 * 2 |
|||||||||
|
Center Wavelength |
nm |
1310 and 1550 |
|||||||
|
Bandwidth |
nm |
±40 |
|||||||
|
Excess Loss |
dB |
≤0.08 (0.06 typ.) |
|||||||
|
Coupling Ratio |
- |
50/50 |
40/60 |
30/70 |
20/80 |
||||
|
Typ. Insertion Loss |
dB |
3.06 |
4.1/2.3 |
5.3/1.6 |
7.1/1.0 |
||||
|
Polarization Dependent Loss |
dB |
≤0.1 |
≤0.1 |
≤0.15/0.1 |
≤0.15/0.1 |
||||
|
Thermal Stability |
dB |
≤0.2 |
≤0.3 |
≤0.4 |
≤0.5 |
||||
|
Directivity |
dB |
≥60 |
|||||||
|
Operating Temperature |
℃ |
-20~+70 |
|||||||
|
Lead Length |
m |
One, others on request |
|||||||
|
Lead Type |
- |
900um, 2mm or 3mm loose tube |
|||||||
|
Package Type |
- |
C |
D |
E |
F |
||||
