PCI Express Ethernet Card 1000Mbps / Port PC network adapter driver Intel 82583V Gigabit Controller

Basic Information
Place of Origin: Guangdong, China(Mainland)
Brand Name: OPTFOCUS
Certification: CE
Model Number: OFS-FL1001F-P1
Minimum Order Quantity: 5 pcs
Price: negotiated
Packaging Details: Normal Package
Delivery Time: 5-8 days after payment received
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 10000 pcs per month
Working Temperature: 0°C-55°C (32°F-131°F) Storage Humidity: 35°C 90%
Working Humidity: 85% Long-range Awaken Function: Support
Network Standard: IEEE802.3 (10G-SR, 10G-LR) Chipset: Intel 82599EN 10G Ethernet Controller
Chipset: Intel 82599EN 10G Ethernet Controller Products Type: 10G1BF-SFP+
Products Type: 10G1BF-SFP+
High Light:

pci express ethernet card

,

fiber optic network interface card



PCI Express Ethernet Card 1000Mbps / Port PC network adapter driver Intel 82583V Gigabit Controller





Type Number: OFS-FL1001F-P1



Brand: OPTFOCUS



Overview



OFS-FL1001F-P1 is the fourth Generation server adapter card ,this is Single-Port Gigabit Ethernet server adapter designed for entry-level servers and Audio-Video applications.

This adapter represents the next step in the Gigabit Ethernet (GbE) networking evolu- tion for the enterprise and data center offering Audio-Video-Bridging (AVB) sup- port, along with power management tech- nologies such as Energy Efficient Ethernet (EEE) and DMA Coalescing (DMAC).



Architected for Small-Footprint Embedded Designs



The Intel 82583V Gigabit Ethernet Controller is a small 9 mm x 9 mm, 64-pin, QFN silicon package that is ideal for GbE implementations on small form-factor embedded designs. The Intel 82583V Gigabit Ethernet Controller consumes less than 750 mW in GbE mode and less than 300 mW in 10/100 mode.The robust design also incorporates optional internal voltage regulation that can reduce the number of voltage supplies required from the platform to power the core and I/O functions.

Support of D0 and D3 power states is provided as well as smart power-down at S0 no link and Sx no link. Support of PCIe power management wake-up and advanced power management (APM) wake-up using special packets is provided as well as a LAN disable function. Some performance-enhancing features include IPv4 and IPv6 checksum offload, TCP/UDP checksum offload, extended Tx

descriptors for additional off-load capabilities, up to 256 KB TCP segmentation (TSO v2), and header splitting.



Key Features



²  Ideal for consumer electronics and other small form-factor embedded applications

²  Low power: < 750 mW GbE and < 300 mW 10/100

²  Operating System Support: Linux*, FreeBSD*, Windows* CE, Windows XP Embedded, and Windows

²  Home Server Extended life cycle support provides seven-year manufacturing availability for customers

²  LAN disable function

²  Full wake-up support

²  Gigabit Ethernet Media Access Control (MAC) and Physical-Layer (PHY) Performance Features

²  Host Offloading Features

²  Additional Device Features



Technical Specification :



Product Code

OFS-FL1001F-P1

Product Name

Server Network Card

Chipset

Intel82583V Gigabit Controller

Bus Interface

PCI Express* V1.1 (5 GT/s) Support

Bus Width

X1 lane PCI Express operable in x1,x4,X8, x16 slots

Data rate supported per port

1000Mbps/Port

Connectors

SFP Slot

Network interface type

Single-Port ,SFP*1,Fiber Optical Card,LC

Network standard

IEEE802.3auto-negotiation

Brackets

Half and full (two brackets)

Intelligent offloads

YES

Operating Temperature

0℃~55℃

Operating Humidity

85%

Storage Temperature

-40℃~70℃

Storage Humidity

90%

Length

10.5cm

Width

6.8cm

Full-height end bracket

12cm

Low-profile end bracket

8cm

Packing Standard Size (Unit)

23*14.6*2.7cm

OS Operation

Windows* XP Service Pack 2 (SP2)

Windows Vista SP1

Windows Home Server

Windows* CE 6.0 (available post-production)

Windows XP Embedded (available post-production)

Red Hat Enterprise Linux* (RHEL) 4.7

Red Hat Enterprise Linux* (RHEL) 5.2

Linux* Stable Kernel version 2.6

SUSE* Linux Enterprise Server (SLES) 9 SP4

SLES* 10 SP2

DOS-NDIS2

FreeBSD* 7.0

Supports PXE



Using Environment



 DELL Server,HP Server,IBM Server,INSPUR Server,Leno Server and other big server brand,

IT System Integrator,Cloud,Big Date Center,Workstation,PC,FTTD Solution(Fiber to the desk) for

Government,institution, School, personal using ,IDC etc.



 Partners and End-Users



China Telecom, China Netcom, China Railcom, China Unicom, Space Unisign servers, Bank of China, Founder Technology, Dawning servers, Lenovo servers, IBM servers, HP servers, Dell servers, the Great Wall Broadband, Beijing Radio and Television General Institute, , World Chinese Youth Federation, Tsinghua Huambo, China Urban Planning and Design, Gehua, The People's Republic of China Ministry of Railways, China City Planning Information Network, etc.
