OEM ODM 10gbps Ethernet Switch 8 Port 10 Gigabit Data Center Switch 8+8

Basic Information
Place of Origin: China
Brand Name: OPTFOCUS
Certification: CE
Model Number: OFS-MXF8GT8-I
Minimum Order Quantity: 1
Price: USD56 per Unit
Packaging Details: Box/Carton
Delivery Time: 7 days
Payment Terms: T/T, Western Union
Supply Ability: 70000 per Month
Product Name: Ethernet Switch Distance: 20km
LOGO: Customized Connector: SC,LC
MOQ: 1 Model Number: OFS-MXF8GT8-I
Place Of Origin: China Warranty Time: 1 Year
Brand: OPTFOCUS
High Light:

ODM 10gbps Ethernet Switch

,

non blocking10gbps Ethernet Switch

,

20km data center switch

Factory OEM/ODM Ethernet Switch 10gbps 8Port 10Gigabit Data Center Switch 8+8 Is a Layer 2/3
Welcome to contact our sales team and they will offer you a professional introduction about our products!

Product Overview

10Gigabit Data Center Switch 8+8 is a layer 2 non-blocking switch with Broadcom chip. Providing 178Gbps switching capacity, with 132.43Mpps forwarding performance, L2 / L3 full wire-speed forwarding. Its flexible networking capability ensures the stability of the network and the balance of the load link. With the modular design, it provides 8 10G SFP+ optical ports, 8 10/100/1000M RJ45 electrical ports, 1 Console port, which offers enough bandwidth for data aggregation and data exchange. With high bandwidth and low latency, pipe network.And in order to flexibly respond to the network requirements, users can select appropriate, 10G ports according to their needs. 10Gigabit Switch is located in high-density access to the core data and the cloud computer network in the next generation, and this product also can be applied for the core and the aggregation of large Internet cafes, enterprise network and metropolitan area network.



Product Model 8+8
Basic Featrue
Fixed Port

8 10G SFP+ optical ports,8 10/100/1000M RJ45 adaptive electrical

ports

Console Port 1
Backplane Capacity 178Gbps
Packet Forwarding Rate 132.43Mpps
Jumbo Frames 12k bytes
Transfer Mode Support store-forward mode and cut-through mode
CPU 600 MHz ARM Cortex-A9 single-core processor
MAC Address Table 16K
Packet Buffer 2MB
VLAN ID 4K
Flash Memory Capacity 8MB
Memory Capacity 512MB DDR3 SDRAM
Soft Specification
Security Feature

IP+MAC+PORT+VLAN binding

ARP inspection

DOS prevention

Port protection

IP source port protection

VLAN

Port based VLAN

802.1Q VLAN

IP based VLAN

MAC based VLAN

MAC Address Table

Static MAC address table

Dynamic MAC address table

Storm Control

Broadcast suppression

Multicast suppression

DLF suppression

Limiting rate

Flow Control

Half-duplex control based on the back pressure type

Full-duplex control based on the PAUSE frame

Port Mirroring Support port mirroring
Port Management

General setting

Port counting

Configuring port

Port trunking

Port-isolation

QoS

IEEE 802.1Qau Congestion mechanism

Each port has 8 transmitting queues mapping 802.1p 8 priority

IP Services

Ping detection

DHCP Snooping

Spanning Tree MSTP(802.1s),STP,RSTP
Multicast Management IGMP Snooping multicasting packets detection
System Management

Support SNMP v1/v2

Support Console

Support TELNET

Support WEB interface

Remote Upgrading

Support version upgrading via web

Support version upgrading via local

Physical Characteristics
Dimension 440mm × 285mm × 44mm
Characteristic of Power AC: 110V~260V
Power ≤100W
Indicator Power indicator, system indicator, connecting / transceiver indicator
Environment Temperature /Humidity operating temperature: 0°C~50°C (0m~1800m) storage temperature: -40°C~+70°C, relative humidity: 5%RH~95%RH, Non-condensing











OEM ODM 10gbps Ethernet Switch 8 Port 10 Gigabit Data Center Switch 8+8 0

Packaging & Shipping

 23



Company Information



Shenzhen OPTFOCUS Technology Co., Ltd was established in 2009, which is a High -tech manufacturer enterprise with 10 years' experience in global sales and services. Our company focus on professional R & D, production and sales of XPON access equipments, FTTH/FTTx solution and passive cabling system products. We also committed to provide Customized OEM & ODM services to Global communication distributors, Telecom Operators and System Integrator. OPTFOCUS manufacturing center covering area around 2,500 Square meter, and owning three production workshops, 9 production lines.



Advantage of our company :

1 National High-tech enterprise certification;

2 Fiber Optical Innovative &production team Over 10 years;

3 Fiber optical active and passive components production Workshop;

4 Strict quality management system;

5 Professional One stop supply & service;

6 OEM&ODM available;

7 Reliable and Timely customer services;



company profile

FAQ:

1. who are we?
We are a 12 years manufacturer specialize in fiber optic communication equipment



2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;



3.what can you buy from us?
Switch,GPON ONU,EPON ONU



4. How many days can shipment after ordered?

According to the quantity you order, we will reply you the shipment day


5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,EXW,FCA;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash;
Language Spoken:English,Chinese or customize
