IP178G 10/100M Ethernet Optical Fiber Switch Auto MDIX

Basic Information
Place of Origin: SHENZHEN,CHINA
Brand Name: OPTFOCUS
Certification: CE
Model Number: OFS-DT8
Minimum Order Quantity: 2 pieces
Price: 4-10 USD/UNIT
Delivery Time: 10 DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000 PCS PER MONTH
Chipset: IP178 Description: 8*10/100M RJ45 Ethernet Fiber Switch
Bandwidth: 100M Moq: 1pcs
High Light:

IP178G Ethernet Optical Fiber Switch


100M Ethernet Optical Fiber Switch


Auto MDIX Fiber Ethernet Switch

10/100M plug and play ethernet european light switch board switch price



8ports 10/100M RJ45 Ethernet Switch



The Fast Ethernet Switch provides 8 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable.


Technical Specifications

Product Name 8 ports 10/100M RJ45 Ethernet switch
Product Model OFS-DT8
Standards IEEE802.3 10Base-T Ethernet IEEE802.3u 100Base-TX Fast Ethernet ANSI/IEEE 802.3 Nway Auto-Negotiation IEEE802.3x Flow control
Chipset IP178G
Frame filtering and forward rate 10Mbps: 14880pps, 100Mbps: 148800pps
Switching capacity 1G
Protocol CSMA/CD
Transfer method Store-and-forward
MAC address learning Automatically learning, automatically Update
Network media(Cable) 10Base-T:2-Pair UTP category 3, 4, 5,5e,6 cable (maximum 100m), EIA/TIA-568 100Ù STP(maximum 100m), 100Base-Tx: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ù STP (maximum 100m)
Operating temperature 0°C~40°C(32 F~104 F)
Storage temperature -40°C~70°C(-40 F~158 F)
Operating humidity 10%~90% non-condensing
Storage humidity 5%~90% non-condensing


*Support IEEE802.3X for full duplex mode operation

*10Base-T, 100 Base-T, and 100Base-FX Operation

*Support Flow control for full duplex mode operation and backpressure for half duplex mode operation

*LED Status of Power on, Link and speed

*Full line speed capability of 148800 (14880) packets/sec for 100M (10m)

*Automatic MDI/ MDI-X Configuration

*Communication distance: Not less than 100M

*Interface: 8 RJ45 Port
