WIFI IP Phone POE 3 Way Conference Wall mount Bracket Single SIP Account

Basic Information
Place of Origin: China
Brand Name: OPTFOCUS
Certification: CE
Model Number: OFS-IPR001
Minimum Order Quantity: 1 pcs
Price: negotiated
Packaging Details: The seller standard export package
Delivery Time: within 3-5 days after get payment
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 10000 pcs one month
Operating Environment: 0°C - 45°C (32°F - 113°F) Operating Humidity: 10 - 90%
Dimension (W X D X H): 170 X 182 X 132mm Power Adapter Jack: 3.5mm,DC 5.0V , 1.0A
Ethernet Ports: 2x 10 / 100 Mbps Weight: 1.0kg
IP Version: IPv4
High Light:

outdoor fiber optic cable


ftth drop cable


WIFI IP Phone POE 3 Way Conference Wall mount Bracket Single SIP Account




The OFS-IPR001 is entry level IP phone for general users with smart esign.

The single SIP account IP phone has been designed  to be the most popular model for daily

communication at office, cost effective but high level performance. With HD voice quality supported and

enhanced speaker box equipped,  it enable a high quality voice experience and all calls on it will be more

like a face-to-face communication.



  • Elegant appearance
  • Full HD Audio (handset, speaker, ringtone)
  • 132 x 52-pixel LCD display with backlit
  • Single SIP Account
  • PoE Support
  • WiFi Connection (Optional)
  • Desktop and Wall-mountable both


Concise appearance  and Small size


The R Series is built for very highest level voice performance. It supports G.722 codec, which covers a

wide range including both low frequency and high frequency bands, and it complies with TIA920

certification  standards,  enable calls  with a HD voice  quailty just like  you're face to  face

communicating with the other party. Furthermore, the Rainbow series have been the first IP phone that

support full HD, such HD handset, HD speaker, and HD ring tones.


HD Voice


With a 132 x 52 dot matrix backlight LCD, multi-language is supported


Easy Configuration


The R series  is supported  Auto Provisioning  by  TFTP / FTP  / HTTP / PnP,  which make installer

configure and maintain all phones easier and more convenient.


Compatible with a  wide range of devices


The R Series  Validated by  Elastix and Broadsoft,  to ensure  an outstanding  compatibility with leading

VoIP platforms.


Display Features


LCD Display:132 x 52  dot-maxtrix


LCD Comtrast:Adjustable

LCD Backlight:Adjustable


Install Option


Desk Mount:Yes

Wall Mount:Yes


Network Features


IP Version:IPv4

IP Assignment:Yes  ( Static / DHCP  / PPPoE )

DNS:Yes  (Primary and Secondary DNS supported)


SNTP Client:Yes

VLAN (802.1Q):Yes

QoS (DiffServ):Yes

NAT Transverse:Yes (STUN mode)

Security:Yes (SRTP / TLS supported)




Power Consumption

Standby:1.0W, Working:2.2W

Operating Humidity:10 - 90%

Operating Environment:0°C - 45°C (32°F - 113°F)

Dimension (W x D x H):170 x 182 x 132mm



SIP Features


SIP Accounts:1

SIP Compatibility: SIP v1 (RFC2543),v2 (RFC3261),

Asterisk,Broadsoft, OPTFOCUS IP PBX


Keys Features


Programmable Keys:0

Features Keys:7 (Menu, Hold, Redial, Mute, Headset, hands-free speakerphone, Message)

Line LED Keys:0

Volume Control Keys:2

Context Sensitive Soft Keys:3

Navigation Keys:4


Configuration and Management


Plug & Play Configuration:Server based configuration Manual Configuration:InternalWeb Configuration,

Local (LCD based) Configuration Auto Provision:TFTP / FTP / HTTP / PnP


Ethernet Ports:2x 10 / 100 Mbps

PoE (Power over Ethernet):IEEE 802.3af Class 2 standard compliant

Headset Jack:1x RJ9

Handset Jack:1x RJ9

Power adapter Jack:3.5mm,DC 5.0V ,1.0A


Audio Features


Ringtones:10+2 user define Ringer Volume:8 levels + off Headset Port: RJ9

Audio Codec:G.711(A/μ),G.722 (Wideband),L16 PCM (Wideband),G.726,G.729AB,iLBC


Software Features


Phone Book (Entries): 100

Call Log Entries: 100 Incoming calls + 100 Outgoing Calls +100 Missed caslls

Conferncing: 3 parties

Music On Hold: Supplied by Host Service (PBX/SIP Server)


Phone Basic Functions:One-Touch, Speed Dial, Redial,Call Forward, Call Waiting,Call Transfer,Call

Hold,Call Return,Mute, Auto answer, DND,Call History: Dialed /Received/Missed, Direct IP Call without

SIP Proxy,Hotline,DailPlan,Set Date/Time Manually or Automatically


Phone Functions with IP PBX: Anonymous Call,Anonymous Call Rejection,DND,Forward, Synchronization Message Waiting Indicator (MWI), Voice Mail,Call Park, Call Pickup Intercom, Paging, Music on Hold ,

Call Recording
