1GE XPON ONU EPON GPON GEPON For optical Network Unit

Basic Information
Place of Origin: China
Brand Name: OPTFOCUS
Certification: CE ISO
Model Number: OFSX511F
Minimum Order Quantity: 500 pcs
Price: 8 usd per pcs
Delivery Time: 7-14 days after payment
Payment Terms: T/T, Western Union
Supply Ability: 10000 pcs per month
Keywords: 1GE ONU Fiber Port: 1*SC
Lan Port: 1*10/100/1000M RJ45 Port Application: Network Unit / Router / Modem
Wavelength: Tx1310 Nm Rx1490 Nm
High Light:

ONU EPON GPON GEPON

,

1GE EPON GPON GEPON

,

Optical Network Unit XPON ONU

1GE XPON ONU EPON GPON GEPON single port for home use optical network unit

1GE XPON ONU EPON GPON GEPON For optical Network Unit 0

OFSX511F XPON(GPON and EPON dual mode) ONU. It is designed for meeting the triple-play service needs of fixed network operators or cable operators, and widely used in FTTx, video surveillance and other requirements. It is based on mature GPON and EPON technology, and has high ratio of performance to price, stable, cost-effective, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees. It is fully compliant with GPON and EPON technical regulations such as ITU-T G.984.x, IEEE802.3ah requirement. it can be used as GPON or EPON.



 Basic Characteristics



Tech parameters
description
Up-link interface
1 XPON interface,SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s(GPON), RX 1.244
Gbits/s rate and TX 1.244 Gbits/s(EPON) rate Fiber type:SC/UPC
Optical power:0~4 dBm Sensitivity:-28 dBm safety: ONU authentication mechanism
Wavelength(nm)
TX 1310nm,RX 1490nm
Fiber connector
SC/UPC connector (SC / APC optional)
Down-link data
interface
1*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface
Indicator LED
4 pcs
DC supply interface
input12V 0.5A
Power
≤5W
Operating temperature
-5+55
Humidity
595%(non-condensation
Storage temperature
-30+70
Dimension(MM)
80*80*22mm(mainframe)
Weight
0.24Kg(mainframe)





Features



Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade, etc.
Completely compatible with GPON international standard IEEE802.3ah/802.3-2005
Support China Telecom GPON CTC3.1 standard and expand OAM
Support DBA reporting mechanism request
Support OAM (Link, Test, Loop back)maintenance function defined IEEE802.3ah
Support to save configured parameters if power down
Support to configure the work mode at the user port
Support MDI-MDIX automatic-detection at the user port.
Support access authentication based on serial number
Support access authentication based on MAC address
Support 802.1Q VLAN
Support traffic rule to modify the related priority.
Support to restore the factory settings
Support the remote reset and reboot
Support dying gasp outage alarm
Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
