Fiber Optic Epon Gpon Onu 1ge 1fe Realtek Chip Catv Wifi Dual Mode Onu

Basic Information
Place of Origin: China
Brand Name: OPTFOCUS
Certification: CE
Model Number: OFSX622-CW
Minimum Order Quantity: 100 pcs
Price: USD 24.5~28 / piece
Packaging Details: 1 piece / box
Delivery Time: 5-10 days, depend on the quantity
Payment Terms: L/C, T/T, Western Union, Paypal and so on
Supply Ability: 50000 pcs / month
Fiber Connector: SC/UPC Or SC/APC DC Supply Interface: Input+12V 1A
WIFI: 2.4G WIFI Rate: 300Mbps PHY Rate
Operating Temperature: -5~+55℃ Keywords: CATV ONU
High Light:

GPON XPON ONU

,

CATV XPON ONU

,

Onu Ont Epon Wifi Router

Fiber Optic Epon Gpon Onu 1ge 1fe Realtek Chip Catv Wifi Dual Mode Onu


1GE+1FE Ethernet ports with Wifi WDM CATV XPON ONU for FTTH solution



Fiber Optic Epon Gpon Onu 1ge 1fe Realtek Chip Catv Wifi Dual Mode Onu 0


Description:


OFSX622-CW XPON(GPON and EPON dual mode) ONU. It is designed for meeting the triple-play service needs of fixed network operators or cable operators, and widely used in FTTx, video surveillance and other requirements. It is based on mature GPON and EPON technology, and has high ratio of performance to price, stable, cost-effective, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees. It is fully compliant with GPON and EPON technical regulations such as ITU-T G.984.x, IEEE802.3ah requirement. it can be used as GPON or EPON.



Basic Characteristics



Tech parameters description



Up-link interface

1 XPON interface,SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s(GPON), RX 1.244 Gbits/s rate and TX 1.244 Gbits/s(EPON) rate Fiber type:SC/UPC

Optical power:0~4 dBm Sensitivity:-28 dBm safety: ONU authentication mechanism

Wavelength(nm) TX 1310nm,RX 1490nm
Fiber connector SC/UPC connector (SC / APC optional)
Down-link data interface 1*10/100Mbps and 1*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface
Indicator LED 7 pcs
DC supply interface input+12V 1A
Power ≤8W
Operating temperature -5~+55℃
Humidity 10~85%(non-condensation)
Storage temperature -30~+70℃
Dimension(MM) 167*119*32mm(mainframe)
Weight 0.6Kg(mainframe)



Features

Ordering Information



Product name Product description
OFSX622-CW 1*XPON(1490nm Rx,1310nm Tx,20Km,SC),1*10/100/1000Base-T,1*10/100Base-T,1*WIFI,CATV,12V Power supply
OFSX622-VW 1*XPON(1490nm Rx,1310nm Tx,20Km,SC),1*10/100/1000Base-T,1*10/100Base-T,1*WIFI,VOIP,12V Power supply
OFSX622-CVW 1*XPON(1490nm Rx,1310nm Tx,20Km,SC),1*10/100/1000Base-T,1*10/100Base-T,1*WIFI,VOIP,CATV,12V Power supply
