    Product Details:

    Place of Origin: Guangdong, China (Mainland)
    Brand Name: OPTFOCUS
    Certification: CE,ROHS
    Model Number: OFS-VPA-1

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: negotiated
    Packaging Details: The seller standard export package
    Delivery Time: within 3-5 days after get payment
    Payment Terms: L/C, T/T, Western Union,Paypal
    Supply Ability: 1000pcs one month
    Contact Now
    Detailed Product Description
    Color: Black Protocol: SIP/H.323
    Operation Temperature: 0 ~ 80℃ Relative Humidity: 10 ~ 65%
    CPU: Ralink MIPS 24KEC(320MHz) SDRAM: 256Mbits
    Flash: 32Mbits



    10 / 100Base-T RJ-45 GSM VOIP FXS Gateway ATA 1 Port SIP H.323 10% - 65% Relative Humidity



    Model: OFS-VPA1



    Voice Feature



    Support SIP 2.0 and correlative RFCs

    Support IAX2 (optional)

    SIP supports 2 SIP servers, public and private server. Can connect to public SIP server and private SIP server at the same time

    Codec: G.711A/u, G.729,G.729a/b, G.726-32k

    Echo cancellation: G.168 Compliance in LEC

    Support Voice Gain Setting, VAD, CNG

    AT transverse: support STUN client

    SIP support SIP domain, SIP authentication (none, basic, MD5), DNS name of server, Peer to Peer/IP call

    Support choose line automatically, using private server to dial automatically when public server disconnected

    DTMF Relay:support inband, SIP info, RFC2833

    SIP application: support call forward/ transfer/ holding/ waiting/ conference

    Call control features: flexible dial map, hotline, empty calling No. reject service, black list for reject authenticated call, limit call, no disturb, caller ID

    Support voice record on SIP server

    Answer or make PSTN call when power is up

    Lifeline support : switch to PSTN call automatically when internet failed or power is off

    Support T.38



    Maintenance and Management



    Web management

    Management with different account right

    Upgrade firmware through POST mode

    Upgrade firmware through HTTP, FTP or TFTP

    Auto Provisioning

    Safe mode provide reliability

    Support Auto Provisioning(upgrade firmware and configuration file)

    Support Syslog



    Network Features



    WAN/LAN: support bridge and router model

    Support PPPoE for xDSL and auto reconnect after disconnected by server

    Support basic NAT and NAPT; Support UPnP

    Support DHCP client on WAN and DHCP server on LAN

    Support IGMP Proxy/IGMP Snooping

    Support ping test with keypad-command

    Support main DNS and secondary DNS server

    Support DNS Relay/ PPPoE Relay

    Support NTP Client

    Support Firewall/ Stateful Packet Inspection(SPI)

    Support Webs URL Filter/Content Filter

    Support MAC/IP/Port Filter

    Support VPN (L2TP/PPTP)

    Support VLAN(802.1Q/P) and VLAN Switch mode

    QoS with DiffServ(Optional)

    Support Virtual Server





    Hardware Specification



    Item

    OFS-VPA1 IP Gateway

    Power Adapter



    Input:100-240V

    Output:12V/1A

    Port

    LAN

    10/100Base-T  RJ-45 for LAN

    PC

    10/100Base-T  RJ-45 for PC

    Phone

    1 RJ11 for Phone (FXS)

    Lifeline

    1 RJ11 for Lifeline

    Operation Temperature

    0 ~ 80℃

    Relative Humidity

    10 ~ 65%

    CPU

    Ralink MIPS 24KEC(320MHz)

    SDRAM

    256Mbits

    Flash

    32Mbits

    Dimension (L x W x H)

    120x77x24mm

    Weight

    0.41kg
