    Product Details:

    Place of Origin: CHINA
    Brand Name: OPTFOCUS
    Certification: RoHS

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 pcs
    Price: negotiable
    Packaging Details: 50 pcs per plate
    Delivery Time: 5-7 days
    Payment Terms: T/T, Western Union, L/C, paypal
    Supply Ability: 10000 pcs per week
    Contact Now
    Detailed Product Description
    Connector Type: SC, LC, FC, ST, MU Wave Length: 1310/1490/1550/1620nm
    Return Loss: UPC ≥55dB; APC ≥65 DB Repeatability: 1000 Times≤ 0.2dB
    Temperature Range: -40 To +85°C

    Fiber Optic attenuator 0-30db attenution SM or MM SC LC FC ST MU connector optional IEC60869



    Fiber Optic attenuator 0-30db attenution SM or MM SC LC FC ST MU connector optional IEC60869



    Fiber Optic attenuator 0-30db attenution SM or MM SC LC FC ST MU connector optional IEC60869



    Fiber Optic attenuator 0-30db attenution SM or MM SC LC FC ST MU connector optional IEC60869





    Specifications:

    Fiber Optic Attenuator
    attenuation fiber inside
    0dB - 30dB attenution
    SC,LC,FC,ST,MU Optional
    SM or MM Optional



    Features:



    1.Based on IEC 60869

    2.Environmentally Stable and Reliable

    3.Accurate Size

    4.High Directivity

    5.Excellent Return Loss



    Technical Standard:

    1.Wave length: 1310/1490/1550/1620

    2.Return Loss UPC ≥55 dB APC ≥65 dB

    3.Repeatability 1000 times≤ 0.2dB

    4.Temperature Range -40 to +85°C



    Application:



    1. CATV

    2. Optical fiber communication systems.

    3. Optical access network.

    4. Optical fiber data transmission.



    Description:





    For SM PC/UPC TYPE For APC TYPE
    Attenuation & Tolerance (dB) 01~10 ± 0.5 01~10 ± 1.0
    11~15 ± 0.75 11~25 ± 1.5
    16~20 ± 1.0
    21~25 ± 1.5
    Durability (dB) 0.2 dB max. increase
    Wavelength (nm) 1310/1550 ± 20 100~250 grams 200~600 grams
    Retention Force 200~600 grams
    Return Loss (dB) ≥55 (UPC Polishing)
    >65 (APC Polishing)
    Operating Temperature -40°C ~ +75°C
    Storage Temperature -55°C ~ +85°C
